Tripod turnstile

stainless steelfor public buildingoutdoor

Traditional turnstile technology precision engineered to suit any modern public transport fare collection system. Simple and effective Classic design with small footprint for indoor or outdoor use Prevents fare evasion Photocell and IR sensors prevent unauthorised passage and fraud attempts Robust and durable 316 grade stainless steel construction for years of reliable use Electro-mechanical head mechanism Positive locking action for one passage at a time Self-centering mechanism to ensure complete rotation into the home position Hydraulic damper to ensure smooth operation Anti-backup device to prevent reverse rotation once the mechanism has moved from 60° from home Interface • LL2001Lite microprocessor control logic • One input for opening/locking in each direction • Two protected outputs controlling opening/locking • Four protected outputs piloting way mode indicators • Two protected outputs counting passage in either direction • Two OV output relays indicating availability of use or counting passage in either direction • Two open collector NPN outputs to count passage or to indicate availability of use in either direction or activate the optional drop arm • Features a Serial Port – RS485 Power failure / Fire alarm • Either one or both directions can be fail-safe (standard), i.e. rotates freely, or fail lock, i.e. locks in the home position • Fire alarm – emergency input. Input facility available for free voltage contact to effect fail-state • Mechanism fail state will be the same as power failure choice • Drop arm option: the horizontal arm drops to create passage for evacuation
