Installation unit HANSA EASYMIX

Product description
HANSA EASYMIX cover part for one outlet (model 88719052) in chrome finish. Designed for concealed wall mounting to minimise visible joints and simplify maintenance. The unit combines EasyMix and the Trim Kit for precise temperature and flow adjustment via dedicated handles. The inner body is manufactured from DZR brass for enhanced corrosion resistance in wet environments, making it suitable for modern shower installations where serviceability and reliable performance are required.

Included / Components

• Rosette plate frame
• Round rosette
• BLUECLICK for screwless trim plate installation
• Function unit
• BLUETUNE alignment after installation +/- 3.5°
• Fastening screws for function unit

Handles

• Temperature control handle
• Flow control handle

Mechanical parts

• Ceramic head part for flow control
• Mixing valve for manual temperature control

Advanced features

• Inner body made of DZR brass for corrosion resistance and long service life
• Concealed wall mounting to reduce leak points and allow easier servicing
• EasyMix and Trim Kit for precise control of temperature and flow

Surface / Finish

• Chrome

Technical specifications

• Brand: HANSA
• Commercial name: HANSA EASYMIX
• Product code / Title: 88719052 Cover part for one outlet
• EAN: 4057304022937
• Finish/Color: Chrome
• Inner body material: DZR brass
• Mounting type: Concealed wall mounting
• Key functions: Temperature control, Flow control, BLUECLICK, BLUETUNE
