Deepened combustion chamber.
A new type of guillotine and service access.
Increased mass for more heat accumulation.
Fireplace insert adapted to recuperation system
FEATURES
Energy class - A
Ecodesign - +
BlmSchV II - +
Nominal power (kW) - 14,5
Heating load range (kW) - 7-19
Thermal efficiency (%) - 78,0
Dust emission [g/m³] - 0,031
Possibility to install the fireplace inserts with warm accumulative casing - NO
CO emission by13% O2 (g/m³) - 0.941
Weight (kg) - 327
Flue diameter (mm) - 200
Air intake diameter (mm) - 125
Glass dimensions (mm) - 680 x 530
Min. active field of outlet vents (cm²) - 1050-1200
Min. active field of inlet vents (cm²) - 600-980
Cartridge with enlarged, deep rectangular combustion chamber giving the possibility of large loads.
Hinged cast iron grate for the convenience of cleaning the hearth.
A new type of guillotine with service access.
Two heat-resistant decorative DECOR windows as standard: working temperature up to 800 degrees.
Possibility to order dedicated masking frames: powder coated steel in the color of the insert.
Steel door made of a special profile that guarantees stiffness and high temperature durability.
Clean glass system: air guide with air curtain.
The elements of the cartridge are manufactured using modern CNC devices: laser 2D, 3D, press brakes.
The insert coat made of P265GH grade boiler steel according to EN 10028-2.
Meets BImSchV II and ECODESIGN standards.
In accordance with the requirements of the Ecodesign Directive within the EU Member States: "This product can not be used as the primary source of heating".
