Acoustic glass panel verre feuilleté

bulletproofsafetyburglar-proof

Overview
Laminated glass is an assembly of at least two glass plies bonded over the full surface by an interlayer. The most common interlayer is PVB (polyvinyl butyral). For exterior applications, EVA (ethylene vinyl acetate) interlayers are recommended for improved water resistance.

References

• Clear laminated glass: 33.2 - 44.2 - 44.6 - 55.2 - 66.2 - 66.8 - 88.2
• Opal laminated glass: 33.2 - 44.2
• Extra white laminated glass: 44.2
• Acid-etched laminated glass: 44.2
• Printed laminated glass 200: 44.2
• Bronze laminated glass: 33.2 and 44.2
• Stopsol clear or bronze laminated glass: 44.2
• Antelio clear laminated glass: 35.2

Acoustic range

• Acoustic laminated glass: 33.2 - 44.2 - 55.2 - 66.2 (reduces noise; also called "silence" laminated glass)

Anti‑burglary laminated glass
Laminated glass compliant with EN 356. Depending on classification, it provides basic protection against vandalism (P1A to P5A) or resistance to forced entry (P6B to P8B). Typical constructions: 44.6 - 66.6 - 66.8 - 444.8 (PS150) - 666.8 (PS150) - PS200.

Bullet‑resistant laminated glass
Laminated glass compliant with EN 1063 providing protection against various firearm types and calibers for high‑risk locations (banks, airports, retail, malls). Suitable for interior and exterior applications. Examples: P4A / BR1-S thickness 14 mm; P5A / BR2-S thickness 19 mm.

Products and applications
Custom cutting and fabrication of laminated glass for interior and exterior fit-outs. Typical uses: printed partition panels, interior workshop‑style atriums, on-site fabrication tables for glazing works.

Technical characteristics / specifications

• Composition: at least two glass plies bonded by an interlayer (PVB common; EVA recommended for exterior use)
• Available types: clear, opal, extra white, acid-etched, printed, acoustic, bronze, stopsol, antelio, decorative
• Standards: EN 356 for anti‑burglary, EN 1063 for bullet resistance
• Example thicknesses and constructions: 33.2, 44.2, 44.6, 55.2, 66.2, 66.8, 88.2, 444.8 (PS150), 666.8 (PS150), 10.10.2, 88.2, 1010.2
• Acoustic laminated glass: specifications available for noise reduction (see references above)
• Applications: cut-to-size, fabrication, balustrades (with tested/approved products per technical dossiers for specific profiles), partitions, security glazing for interior and exterior use
