HR-LINE Extrusion
Ref: B3579
HR-LINE frosted cover and densely spaced LEDs inside the extrusion will provide an effect of an even line of light. Due to its high integrity and high load bearing capacity, the extrusion is ideal for high-traffic areas such as sidewalks, bike paths, environment friendly.
Patent Number: US 8,267,540 B2
Designed to obtain an IP67 waterproof rating
Designed to reach IK10 degree of protection against mechanical impact Resistant to pedestrian and road traffic
Technical specification
Application
- construction of watertight, ground lighting fixtures inside and outside buildings (walkways, car parks, driveways)
Assembly
- mounted on spacer foam in a prepared gap in the hardened surface (e.g. paving stones)
- the remaining gap is filled with sand
Additional information
- dedicated glands must be used for the correct application of the profile
- water-tight splitters and couplers are used to run the cables powering the light fixture in the ground
- it is extremely important to properly seal HR-LINE components ( extrusion, covers, end caps, LEDs) if the fixture are assembled by KLUS
- for sealing HR-LINE extrusion we recommend using – DOW CORNING 3145 , transparent Neutral Silicone
- when choosing other sealing materials it is important to know their quality, applications and that they do not conduct electricity
- the quality of HR-LINE extrusion sealing depends solely on the quality and precision of the sealing process as well as the quality of the sealing material
- profile construction makes it durable and sturdy, resistant to standard loads (up to 20 kN)
- space for LED strip: 0.48" / 12.2 mm
