Espresso coffee machine M40

commercialsemi-automatic2-group

Overview
The LaCimbali M40 is a commercial traditional espresso machine engineered for high throughput, energy efficiency and improved barista ergonomics. It integrates modern materials and digital control to meet demanding professional environments while reducing operating costs.

Design
Designed by Valerio Cometti + V12 Design, the M40 harmonises styling with LaCimbali's M200 range while offering form variants for different operational layouts. The chassis is built in die-cast aluminium and steel for durability and reduced weight.

Ergonomics
Coffee groups are positioned away from steam wands and centered on the machine to streamline workflow. The M40 is approximately 30% lighter than the previous M39 reference and includes a removable espresso platform for fast recipe setup. Steam wands feature COLD TOUCH coating to minimise burn risk and speed up service.

Digital interface
A fully redesigned tempered-glass, full-touch capacitive panel provides rapid access to programmable recipes, configurable icons and operator controls. Panel width and tilt are optimised for barista ergonomics and efficient service.

Technologies

• TURBOSTEAM MILK4: patented device allowing configuration of 4 distinct milk recipes.
• COLD TOUCH: coated steam wand preventing contact with hot parts.
• TELEMETRY: remote monitoring and management capabilities for fleets.
• CUP4YOU: recipe delivery and integration system.
• PGS (Perfect Grinding System): supports optimal grinding parameters.
• BDS (Barista Drive System): barista-focused operational controls.
• ECO-SMART THERMAL SYSTEM: centralized energy-efficient heating for repeatable dispensing temperature and immediate temperature selection via display.

Accessories
Optional accessories listed on the product page include the G50 grinder-doser and other workflow components to complete the coffee station.

Certifications
Displayed certifications: ROHS, TIFQ, NSF, UL (EU), CE and D (as shown on product documentation).

Performance & Sustainability Highlights

• Reduced ignition time: ~6 minutes (≈ -50% vs M39 DOSATRON, internal tests).
• First heating consumption reduced by ≈ -55% vs M39 DOSATRON (internal tests).
• "Ready to use" mode consumption reduced by ≈ -55% vs M39 DOSATRON (internal tests).
• Operational energy impact: ≈ -55% reduction in "Product Usage" (kg CO2-eq.), excluding production/disposal impacts.

Maintenance & Total Cost of Ownership
The M40 is engineered to reduce maintenance time (~ -30% vs M39 DOSATRON, internal tests). A single removable group block replaces the traditional carter group to accelerate both routine and extraordinary maintenance; many basic adjustments are accessible without technical intervention.

Downloads
The product page provides a brochure and a multilingual manual for installation, operation and maintenance.

Technical specifications

• Denomination: M40
• Configurations: available in 2-group and 3-group versions; finishes in white and black shown.
• Body materials: die-cast aluminium and steel.
• Weight: approx. 30% lighter than M39 reference.
• Ignition time: approx. 6 minutes (≈ -50% vs M39 DOSATRON, internal tests).
• Energy improvements: ≈ -55% first heating, ≈ -55% ready mode (vs M39 DOSATRON, internal tests).
• Thermal system: ECO-SMART centralized heating, selectable dispensing temperature.
• Milk system: TURBOSTEAM MILK4, compatible with COLD TOUCH wand.
• Connectivity: TELEMETRY remote monitoring, CUP4YOU integration.
• User interface: tempered glass full-touch capacitive keypad, fully customisable recipes and icons.
• Grinding/extraction support: PGS (Perfect Grinding System), BDS (Barista Drive System).
• Maintenance: single removable group block for faster maintenance; many user adjustments without technical intervention.
• Certifications: ROHS, TIFQ, NSF, UL (EU), CE, D.
