display totem / for public spaces
for public spaces
The load-bearing structure of the two-faced totem is made in steel sheet, 30/10 thickness. The base of the totem (dim. 180 X 850 mm) is made in polished stainless steel AISI 316 , 80/10 thickness, provided with 8 holes 12 mm diam. For the fixing to the ground through specific bolts (not provided). The upper part of the tomem has a small roof in stainless steel AISI 316, 30/10 thick, sticking out to help with the drainage of rainwater and avoid infiltrations on the inside. The display surfaces (dimensions: 650 x h 1000 mm) are made in galvanized steel sheet, 10/10 thickness, and are fixed to the load-bearing structure through 4 screws M5. The display surfaces are protected by 2 panels in tempered crystal glass, 8 mm thick, supported by strong elements provided with a lock.
Steel EN10111DD11 is used for the realization of this product and all the elements in this material, after all the different stages (cutting, bending, welding), are treated with electrogalvanizing according to the UNI regulations and are later polyester powder-coated with RAL colours at choice.
As an alternative to steel EN10111DD11, the production in corten is also available, on demand. In this case the material is treated with a specific oxidation process.
The galvanized steel used is steel EN10346DX51D+Z and, unless otherwise stated, is not painted.
