False ceiling acoustic panel LINEA BAMBOO

Douglas firsolid woodoak

Product description
Slatted solid wood acoustic panel designed for suspended ceilings. Suitable for visible linear ceiling designs in architectural interiors.

Versions / Mounting

• To be installed on T24 grid
• To be screwed onto metal or wooden frame

Acoustic performance

• Weighted index: αw = 0.70
• Absorption class: Class C
• Various sound absorption data (αp, αw, absorption class) calculated in accordance with ISO 11654 (Linea + acoustic complement + 20 mm rockwool on E250 mm plenum)
• Sound absorption measured in accordance with ISO 354

Finish / Reaction to fire

• Fire-retardant, Euroclass standard B-s1, d0 or B-s2, d0 depending on the type of wood and finish

Installation standards

• Installation on T24 grid or by screwing
• In accordance with NF EN 13964
• In accordance with DTU 58-1

Back panel

• Rigid acoustic rockwool slabs (2.4 kg/m²), covered with black fleece finish (size: 600 x 600 mm; thickness: 20 or 22 mm)
• Not supplied by Laudescher

Wood and finishes

• Timber species: Pine, Oak
• Slat finishes: Clear varnish
• Wax colour finishes available: White, Douglas, Oak, White oak, Cenza, Green, Wenge, Black
• Other colours on request
• Clear varnish required for sensitive environments

Technical specifications

• Panel dimensions: 2495 x 600 mm (screw-on only); 1880 x 600 mm; 1265 x 600 mm
• Slat cross-section: 40 mm (face) x 40 mm (height)
• Slat spacing: 35 mm
• Centre distance of slats: 75 mm
• Black rear counter-slats: 34 x 45 mm
• Total thickness: 75 mm
• Timber species: Pine, Oak
• Area density (pine): 13.2 kg/m²
• Area density (oak): 15.2 kg/m²
• Openness percentage: 47 %
• Weighted index: αw = 0.70; Absorption class: C
• Back panel (not supplied): Rigid acoustic rockwool slabs (2.4 kg/m²) covered with black fleece (600 x 600 mm; thickness 20 or 22 mm)
• Standards: ISO 11654, ISO 354, NF EN 13964, DTU 58-1
