Recessed downlight RD6-WH-TW

recessed ceilingfor ceilingLED

Overview
The Lumaris retrofit downlight is a 2-channel tunable-white luminaire with a 4 in aperture designed for fast installation into standard 5" or 6" recessed housings. It installs without special tools or additional control wiring and delivers 800 lm of ambient light with consistent color rendering and flicker-free dimming to 0.1%. Compatible with Lutron wireless systems to enable automated day-to-night transitions and advanced sun-tracking features.

Highlights

• 2-channel tunable white (1,800K–4,000K) with consistent CRI >90
• Incandescent-like dimming behavior with precise color temperature control
• 800 lumens ambient output suitable for residential and light commercial spaces
• Quick retrofit into existing 5" or 6" recessed housings without rewiring
• Trim options: white or black
• Native wireless control via Lutron Clear Connect Type X (no low-voltage control wire required)

Light Engine

• 2-channel tunable white
• CCT range: 1,800K–4,000K
• Color rendering: CRI >90

Wireless Control
Native wireless integration using Lutron Clear Connect Type X. Designed to work with HomeWorks, RadioRA 3, Athena, and myRoom XC systems for centralized control and automation.

Dimensions
H 2.7 in (68.6 mm) x L 7.2 in (182.9 mm) x W 7.2 in (182.9 mm); Aperture: 4 in; Minimum recessed housing depth: 3.0 in (76 mm).

System Compatibility

• HomeWorks QSX
• RadioRA 3

Technical specifications

• Light Engine: 2-channel tunable white
• CCT Range: 1,800K–4,000K
• Color Rendering: CRI >90
• Delivered Lumens: 800 lm
• Dimming Range: 0.1%–100%
• Rated Life: 50,000 hours to L70
• Power Consumption: 8.5 W
• Voltage: 120 V ~ 60 Hz
• Current: 0.07 A
• Environmental Rating: IP20 indoor dry / damp location
• Certifications: cULus listed; FCC approved; Industry Canada certified; California Title 24 / JA8 compliance as applicable
• Warranty: 5 year fixture, LED and dimming warranty
