The Astoria Classic will appeal to purists who want clean, authentic all-valve tone, and to boutique pedal enthusiasts who will find it the perfect pure-valve foundation for their sound.
The Power Reduction pull switch drops the amplifier’s output power from 30 Watts to 5 Watts, which produces softer tones and a less ‘in your face’ sound.
The Sensitivity control optimises the sensitivity of the preamp by controlling its negative feedback. It increases or decreases gain without changing the output impedance of the first stage. This means that tonal integrity is preserved regardless of where the Sensitivity control level is set.
Edge makes the overall characteristic sound of the amplifier brighter or darker. To achieve this, it cuts high frequencies between the phase splitter and the power valves. Edge is a power stage function with a similar effect to a traditional presence control. Note that he higher the Master volume level, the more pronounced the Edge function will become.
General
MODEL NAME - ASTORIA CLASSIC
RANGE - ASTORIA
TECHNOLOGY - VALVE
CHANNELS - 1
Electronics
WATTAGE - 30W
INPUTS - HI/LO (HI provides +6dB Sensitivity)
CONTROLS - MASTER, SENSITIVITY, TREBLE, MIDDLE, BASS, EDGE
Speakers
SIZE - 1 x 12"
OUTPUT POWER - 75W
NAME - CELESTION CREAMBACK
IMPEDANCE - 4 / 8 / 16 Ohm
Valves
PRE AMP VALVES - 3 x ECC83 (12AX7)
POWER AMP VALVES - 2 x KT66
Accessories
FOOTSWITCH - NONE
CABLES - POWER
Dimensions
HEAD WEIGHT (KG) - 16.5
HEAD DIMENSIONS in mm
(W x H x D) - 600 x 290 x 230
COMBO WEIGHT (KG) - 27.5
COMBO DIMENSIONS in mm
(W x H x D) - 600 x 540 x 260
