Front-loading dishwasher MEIKO TF-L / TP-L

for cateringrecessedeco-friendly

Overview
The MEIKO single-chamber trolley washers (TF-L front-door and TP-L pass-through) are cleaning systems engineered for inflight catering operations. They wash and dry up to two airline trolleys per cycle and provide hygienic cleaning and rapid turnaround for reuse. Compatible with full-size, half-size, light and standard airline trolleys. Can be installed as a front loader or pass-through, in a pit or with ramp installation options.

Key benefits

• Reliable hygienic cleaning tailored to catering hygiene requirements
• Integrated 360° airflow drying for both interior and exterior surfaces
• High throughput: consistent temperatures maintained at high processing rates — up to 40 trolleys/hour including drying
• Efficient water use: approx. 5 L water per trolley
• Compact footprint: under 4 m², suitable for constrained galley or ground handling areas
• Durable stainless-steel construction and double-walled cabinet design for long service life

Main features

• Two models: MEIKO TF-L (front-door) and MEIKO TP-L (pass-through)
• Flexible installation: pit installation or ramp installation (TF-L: single ramp option; TP-L: two-ramp option with output indicator light)
• Four powerful wash systems and high final rinse temperature (thermal disinfection option available) to meet strict hygiene standards
• Built-in heat recovery that returns energy to the washing process to reduce consumption and improve working climate
• Self-cleaning sequence integrated into the heat-recovery cycle
• Clear blue-colour operating concept indicating operable and cleanable parts
• 7-inch colour touchscreen with guided operator instructions
• Interior lighting and emergency unlocking for safe maintenance
• Advanced straining and filter technology plus drain pump with large openings for efficient removal of soil
• Rotating plate secures trolleys in tilted position and ensures all-round cleaning of interior and exterior surfaces
• Service-friendly external access to electrical cabinet and chemical interface; compatible with MEIKO Connect for protocol and service data

Application
Designed for inflight catering providers and airline ground handling operations that prepare large meal volumes. Effectively removes food and beverage residues and reduces microbiological load to prepare trolleys for hygienic reuse.

Technical specifications

• Models: MEIKO TF-L (front door), MEIKO TP-L (pass-through)
• Throughput: up to 40 trolleys per hour (including drying)
• Capacity per cycle: up to 2 trolleys
• Water consumption: approx. 5 L per trolley
• Final rinse temperature (hygiene/thermal disinfection): 81 °C
• Footprint: under 4 m² (example footprint: 1.64 m × 2.19 m)
• Drying: integrated 360° airflow (airflow channels and cooling fan)
• Construction: stainless-steel wash nozzles, stainless-steel heat exchanger and pump casing; double-walled doors and cabinet
• User interface: 7-inch colour touchscreen
• Installation: pit installation or ramp installation (TF-L: 1 ramp; TP-L: 2 ramps)
• Additional: built-in heat recovery, self-cleaning support, interior lighting, emergency unlock, advanced filter and straining technology
