Dimensions: Ø 30 mm, A=300 mm, B=330 mm, E=165 mm, D=85 mm. Pull handle in aluminium. Curved L-shaped. Pull handle Ø 30mm. Support centre to centre distance A=300 mm. Overall dimension B=330 mm. Side overall dimensions E=165 mm. Overhang D=85 mm. Round end supports Ø=30 as the pull handle. Can be installed on aluminium, glass, wooden, PVC doors and mixed systems using the PBA fixing kit, to be ordered according to the material. Patented anti break-in fixing system. PBA D-type fixing. Standard finish: Black powder coating, white RAL 1013, white RAL 9010, silver anodized, self coloured (on request: bronze anodized, black anodized; other colours on request).
Aluminum
.26 - POWDER COATED Black
.21 - POWDER COATED White 1013
.30 - POWDER COATED White 9010
.62 - ANODIZED Silver
.61 - UNFINISHED
.63 - ANODIZED Bronze
.64 - ANODIZED Black
