Acoustic glass panel INSULIGHT™ PHON

solar controlinsulatingthermo-acoustic insulating

Overview
Pilkington Insulight10 Phon is Pilkington's acoustic insulating glass unit (IGU) range designed to improve noise control in buildings. Recommended for urban and high-noise environments, it is suitable for facades, windows and internal partitions in commercial and residential projects.

How it works

• Combines panes of different thickness (recommended ~30% thickness difference, e.g., 6 mm and 10 mm) to disrupt sound transmission.
• Uses Pilkington Optilam10 laminated glass with PVB interlayers to add mass and damping.
• Can include Pilkington Optiphon10 laminated sound-absorbing glass with special foil for enhanced acoustic insulation.

Features & Benefits

• Available in double and triple glazed IGU configurations to meet project performance requirements.
• Wide range of acoustic parameters and high sound attenuation coefficients for targeted noise reduction.
• Compatible with other Pilkington glass ranges to combine acoustic, thermal and solar control properties.
• Suitable for internal and external use: facades, windows, ventilated façades, internal partitions and glazed screens.
• Options for laminated constructions to improve safety, security and acoustic performance.

Spectrum Calculation Program
Pilkington Spectrum is the referenced performance modelling tool for calculating key IGU properties including light and solar metrics (transmittance, reflectance, absorptance, g-value), centre-pane U-value, sound insulation values, Global Warming Potential (GWP), ultraviolet transmittance and colour rendering index.

Technical specifications

• Product type: acoustic-optimised insulating glass units (IGUs).
• Construction: combinations of monolithic panes, laminated panes and sound-absorbing laminated glass.
• Recommended pane thickness variance: approximately 30% difference between panes (example: 6 mm + 10 mm).
• Laminated options: Pilkington Optilam10 (glass with PVB interlayers).
• Acoustic laminated option: Pilkington Optiphon10 (laminated, sound-absorbing glass with special foil).
• Configurations: available in double and triple glazing.
• Applications: facades, windows, internal partitions; suitable for urban noise mitigation in commercial and residential projects.
• Performance: elevated noise attenuation coefficients with a broad selection of acoustic specifications.
• Compatibility: can be combined with other Pilkington glass products to achieve additional thermal or solar control benefits.
• Environmental: EPD verification referenced for insulating glass units.
