Safety glass panel OPTIPHON™

insulatingacousticlaminated

Overview
Pilkington Optiphon™ is an acoustic laminated glass designed to reduce airborne noise while maintaining light transmittance and safety. Acoustic performance is achieved by combining glass of various thicknesses with a special PVB (polyvinylbutyral) acoustic interlayer. Multiple product combinations allow tailoring to specific noise-reduction requirements.

Combined use and benefits
Pilkington Optiphon™ can be used as monolithic laminated glass or incorporated into insulating glass units (e.g. Pilkington Insulight™ Phon) to deliver combined acoustic and thermal performance. It can be combined with Pilkington solar-control or self-cleaning products for additional functionality.

Features & Benefits

• Suitable for internal and external applications.
• Can be single glazed laminated or incorporated in insulating glass units for increased sound insulation.
• Provides a range of noise-control levels depending on configuration.
• Compatible with other Pilkington products for added thermal, solar-control or self-cleaning properties.
• Safety glass meeting impact safety requirements of EN 12600.
• Available in clear or decorative finishes.
• Standard nominal thicknesses: 6.8 mm, 8.8 mm, 9.1 mm, 10.8 mm, 12.8 mm, 13.1 mm; many combinations possible.
• Bespoke configurations available to meet project-specific requirements.
• Thin, lightweight solution for noise reduction where space or weight is critical.

Applications
Pilkington Optiphon™ is suitable where noise from road, rail, air traffic or industrial and entertainment sources needs control. Typical applications include windows, facades, internal partitions and locations requiring acoustic privacy such as offices, lecture theatres and hospitals.

Technical specifications

• Product type: Acoustic laminated glass.
• Interlayer: Special PVB (polyvinylbutyral) acoustic interlayer.
• Performance: Provides varying levels of sound reduction depending on glass thickness and composition.
• Safety: Conforms to impact safety requirements of EN 12600.
• Finishes: Clear or decorative finishes available.
• Standard nominal constructions / thicknesses: 6.8 mm, 8.8 mm, 9.1 mm, 10.8 mm, 12.8 mm, 13.1 mm.
• Installation: Usable monolithically or within insulating glass units for combined thermal and acoustic performance.
• Customization: Bespoke configurations available to meet project-specific noise reduction requirements.
