Self-cleaning glass panel ACTIV™ RANGE

safetysolar controlacoustic

Overview
The Pilkington Activ™ Range is a family of self-cleaning float glass designed for architectural glazing. Variants combine a hydrophilic photocatalytic coating with optional solar-control treatments to reduce maintenance and improve visual comfort for windows, facades, canopies and skylights.

Products in the Range

• Pilkington Activ™ Clear: clear float glass with self-cleaning properties
• Pilkington Activ™ Bronze: bronze body tinted float glass with self-cleaning and solar control properties
• Pilkington Activ™ Blue: blue body tinted float glass with self-cleaning and medium solar control properties
• Pilkington Activ SunShade™ Neutral: clear float glass with neutral coating offering self-cleaning and medium solar control properties
• Pilkington Activ SunShade™ Blue: blue body tinted float glass with self-cleaning and high solar control properties
• Pilkington Activ Suncool™: high performance solar control glass with self-cleaning properties

Product combinations

• Self cleaning: Pilkington Activ™ monolithic, single-coated, used as single or in insulating glass units
• Self-cleaning + solar control: Pilkington Activ Suncool™ monolithic, dual-coated, used in insulating glass units
• Self-cleaning + safety: Pilkington Activ Optilam™ laminated safety glass, coated, used as single or in insulating glass units
• Self-cleaning + noise control: Pilkington Activ Optiphon™ sound insulating laminated safety glass, coated, used as single or in insulating glass units
• Self-cleaning + thermal insulation: Pilkington Activ Optitherm™ monolithic, dual-coated, used in insulating glass units

Other configurations
Other configurations are possible (for example Pilkington Activ Suncool Optilam™). Pilkington Activ™ can be combined with other Pilkington products in insulating glass units (for example Pilkington Insulight Activ™) to add properties such as impact resistance, increased security, acoustic insulation and improved thermal performance.

Features & Benefits

• Photocatalytic coating breaks down organic dirt under UV exposure, facilitating removal by rain or rinsing
• Hydrophilic surface causes water to form a uniform sheet that washes loosened dirt away and dries quickly
• Continues to reduce surface soiling even in cloudy conditions
• Improved visibility during and after rain compared with uncoated glass
• Reduces cleaning frequency and maintenance costs for hard-to-reach glazing such as skylights and high facades
• Compatible with laminated and insulated glazing constructions to meet safety, acoustic and thermal requirements
• Pilkington Activ™ Clear is visually similar to standard clear glass when used monolithically

Spectrum Calculation Program
Pilkington Spectrum is a Windows-based glass performance model enabling fast calculation of key properties for single glazing and insulating glass units. The program provides:

• Light and solar properties (transmittance, reflectance, absorptance, g-value)
• Centre-pane U-value
• Sound insulation values
• Global Warming Potential (GWP) or carbon footprint
• Ultraviolet (UV) transmittance and colour rendering index (Ra)
• Other properties such as impact resistance, fire resistance and resistance to manual attack

Technical specifications

• Product type: self-cleaning float glass family with variants offering different solar control performance
• Available variants: Activ™ Clear, Activ™ Bronze, Activ™ Blue, Activ SunShade™ Neutral, Activ SunShade™ Blue, Activ Suncool™
• Coating types: monolithic single-coated (Activ™), monolithic dual-coated (Activ Suncool™, Activ Optitherm™), coated laminated options for safety and acoustic performance
• Form factors: used as monolithic single glass or incorporated into insulating glass units; available laminated safety combinations (Optilam™, Optiphon™)
• Main functions: photocatalytic decomposition of organic dirt under UV; hydrophilic surface causing water to sheet and wash away loosened dirt
• Performance notes: continues to work in cloudy conditions; improves vision in wet weather; reduces cleaning frequency and maintenance costs
• Typical applications: windows, facades, canopies, skylights and other hard-to-reach glazing
• Compatibility: can be combined with other Pilkington glass products (e.g. Pilkington Insulight Activ™) for added properties such as thermal insulation, impact resistance and noise control
