Precast beam TRAVI

steelaluminumU-shaped

Summary
Our patented high-capacity H25 lattice beams reduce stacking issues and operator fatigue during erection of temporary works. They deliver a lightweight, easy-to-handle solution for shoring, formwork and temporary decks where reliable beam performance is required.

Characteristics
H25 beams are available in aluminium and steel and in three functional versions:

• TT: compatible with all major plank brands on the market
• UT reverse: designed to accept steel planks with a tube connection on one side and planks with a U-profile connection plus panel stop on the other
• UTL: fitted with a multilayer wood batten on one side for use in propping or to create planked work surfaces

Advantages

• Enable perfectly coplanar working surfaces when coupled with appropriate connection elements
• Faster assembly using patented spring pins instead of locking bolts
• Reduced weight and compact dimensions lower transport, handling and storage costs

Applications

• Residential construction
• Skyscrapers
• Industrial buildings
• Bridge construction
• Bridge maintenance
• Renovation & Restoration
• Oil & Gas sites
• Events and temporary structures

Technical specifications

• Product family: H25 lattice beams
• Materials: aluminium or steel
• Versions: TT, UT reverse, UTL
• TT version: compatible with major plank brands
• UT reverse: for steel planks with tube connection on one side and U-profile connection with panel stop on the other
• UTL: multilayer wood batten on one side for propping or planked work surfaces
• Patented design: high-capacity lattice beam to reduce stacking problems and fatigue
• Connection options: compatible with connection elements to create coplanar surfaces
• Assembly: supports use of patented spring pins for faster operations
• Logistics: reduced weight and compact dimensions to minimize transport, handling and storage costs
