Precast beam IXI TRUSS

load-bearingsteelaluminum

Overview
The IXI truss beam is a modular aluminum truss designed for lightweight, weather-resistant structural applications. Engineered for ease of transport and rapid on-site use, it is suited to temporary and permanent installations where reduced mass and fast assembly improve project logistics and timelines.

Applications

• Bridges
• Large-span roofs
• Walkways
• Elevated platform support
• Material scaffolding

Advantages

• Reduced logistics costs: stackable and easily transportable, allowing over 300 m to fit in a standard container.
• Increased efficiency: fast assembly saves time and improves project competitiveness.
• Durability: corrosion-resistant aluminum for long-term use in harsh environments.
• Quick installation: can be assembled on the ground or in the air without special tools or specialized operators.

Technical specifications

• Material: Aluminum
• Weight: 18.5 kg/m (12.4 lbs/ft)
• Modular lengths: 1 m, 2 m, 3 m
• Vertical tube spacing: every 1 m for adaptability
• Compatibility: Ringlock compatible
• Relative mass: approximately 5× lighter than equivalent steel beams
• Logistics: stackable; >300 m can fit in a standard container
