Strobe/Dimmer
Double flag strobe,0.3-25 F.P.S. / linear dimmer
Movements
Pan (0°-540°),Tilt( 0°-270°) with auto positioning correction function
Beam angle
Beam/Spot mode angle:0.8°-26°
Wash mode : 1.8°-30°
Unique super wide angle/under wash mode : 38°-60°
Control
International standard DMX 512 signal ,5-pin XLR connectors
Short Mode 23 channels,standard Mode 28 channels, extended mode 31 channels
Self test mode
Other functions
Pan and Tilt speeds adjustable
Lamp hours and fixture hours displayed
Modular construction easy for maintenance
Wireless receiver
Wireless transmitter ( Optional)
ArtNet control( Optional)
Housing and ingress protection
Cast aluminum and high temperature and UV resistant ABS with IP66
Weight
Net weight:37.8Kg
Ambient temperature
45 °C at maximum
Note: If the ambient temperature is below 0°C, preheat the fixture for some time( less than 20 min based on actual situation normally) before striking the light source
