Infiltration tunnel 7100088260

Product overview
The tunnel system has been specifically developed for the underground infiltration, retention and storage of rainwater. The system is utilized in applications ranging from small-scale drainage tasks to large-scale commercial and industrial projects. The solution enables decentralized infiltration to reduce the burden on sewer systems and to mitigate flood risk. It is imperative to ensure that only uncontaminated water is introduced into an infiltration system.

Suitable runoff sources

• Non-metallic roof surfaces in residential areas
• Terrace surfaces in residential areas

Installation and maintenance
With proper installation and sufficient cover, infiltration tunnels are suitable for loaded areas (for example parking lots or trafficked areas). Maintenance is carried out via connected shafts and pipelines; the system can be flushed and inspected using camera technology to ensure safe long-term operation.

Technical data and dimensions
7100088260 | 120 x 80 x h 40 cm | 11 Kg | 310 l/m
7100088380 | 70 x 40 cm | HD PE (material) | -

Accessories / Components
An end plate is attached at the beginning and end of each row of elements to close off the system. The plates are perforated to allow for the quick integration of piping (diameters between 60 and 230 mm).

Characteristics / technical specifications

• Denomination commercial: ROTO Infiltration tunnel
• Brand: ROTO
• Product code: 7100088260 — Dimensions: 120 x 80 x h 40 cm; Weight per piece: 11 Kg; Capacity: 310 l/m
• Accessory code: 7100088380 — End plate: 70 x 40 cm; Material indicated: HD PE; perforations for piping diameters 60–230 mm
• Pallet goods: max. 40 tunnels per pallet
