Stainless steel railing DECOR

steelglass panelindoor

Features Pole with fine mounting bracket Glass railing for balcony, staircase, porch house, espace public… Design system with glass adjustment (horizontal) Validated under test reports Good price/performance ratio Post dimensions: 60 x 15 mm Standard in 304 stainless steel – available in 316 stainless steel or painted steel for posts Validated glass dimensions: 1 000 and 1 500 mm: thickness 8.8 Dimensions / Type* Tailored products and solutions on demand > Flat post 50 x 20 mm Materials Stainless steel AISI 304 Stainless steel AISI 316 Steel ready to paint Glasses 13,52 -> 17,52 mm 19 -> 21,52 mm 21,52 -> 25,52 mm Tailor-made Flat railing whit Posts An effective and economic fixing Discover the SADEV 50 x 20 railing with post and flat glass connectors (Decor range). This system allows an easy installation with many adjustments available. This railing is able to bear a weight up to 100kg. We advice you to use tempered glass, with a glass thickness between 12 and 25.5 mm. This system has been tested and approved for an installation in public places (CEBTP, French official test center) for a 8.8/4 glass thickness and a length between 1100 and 1500 mm. Technical informations Economic system including installed glass adjustment. Many adjustments available : horizontal, vertical. Private and public application. Certified by the CEBTP. Easy ton install. Standard in 304 Stainless steel, available in 316 painted steel for the posts. Reference : 0060200228
