Aluminum profile room divider V70

glassaluminumfor office

The V70 full-height glass partition is a modular internal glazing solution (SYMPHONEE range) designed to create bright, modern room dividers with clear sight lines while allowing quick installation of glass or decorative infill panels.

Overview

• Two-component aluminium profiles interlock to receive 6–8 mm glass or decorative panels.
• Profiles are cut square (90°) and assembled using brackets tightened inside the profiles; discreet spacers ensure precise positioning of infill panels.

Assembly and components

• Bracket-based assembly with screws secured inside profiles for a flush, concealed finish.
• Clip-on glazing beads simplify glazing and replacement operations.
• Main assembly elements presented in technical imagery: Frame, Cross profile, Clips.

Customisation

• Infill options: 6 mm or 8 mm glass, or decorative panels.
• Modular profile widths: flat adhesive profiles available in 25 mm, 30 mm and 40 mm for configuration flexibility.
• Profile finish options including the "Colour collection by SEED".
• Dual-colour interior/exterior finish available via the clip-on concept.
• Easy integration of a hinged door; integrated door options available.

Available items & visual resources

• Product images and technical drawings: profile views (V70), plan/cut drawings and accessory/profile tables provided on the product page.
• Documentation: downloadable product flyer (English PDF) available from the product page.

Technical specifications

• Series / model: V70 (SYMPHONEE full-height partition).
• Suitable infill thickness: 6–8 mm (glass or decorative panels).
• Profile preparation: square (90°) cuts; assembly with internal brackets and fixing screws; clip-on glazing beads.
• Modular profile widths: 25 mm, 30 mm and 40 mm (flat adhesive profiles).
• Acoustic performance: sound reduction index RA,tr up to 36 dB.
• Profiles designed with optimized wall thickness for cost-effective manufacture.
• Panel width range: 400 mm to 10,000 mm.
• Panel height range: 400 mm to 2,700 mm.
