Features - popular size,small size,high efficiency solar cell A grade poly solar panel
Product Name - 12v poly panel solar 20w Battery Charger Backup for industrial use street light guard station
Maximum Power[Wp] - 20
Solar Cell - Poly A grade solar cell
Cell size[mm] - to be confirmed with solar sales representative
Cell Array[Pcs] - 3*12
Cell Efficiency - 18.44%
Size[mm] - 430*340*25
Max Power Voltage Vmp[V] - 19.08
Max Power Current Imp[A] - 1.05
Open Circuit Voltage Voc[V] - 22.51
Short Circuit Current Isc[A] - 1.14
Net.Weight[kg] - 1.2
Power tolerance[ - ±3%
NOCT[ - 45±2
Operating Temperature[ - -40/+85
Temperature Coefficient Pmax[%/ - -0.41
Temperature Coefficient Voc[[%/ - -0.32
Temperature Coefficient Isc[[%/ - 0.04
Maximum System Voltage[V] - 1000 V
Certification - CE ROHS
