Safety glass panel ŞIŞECAM DECO PATTERNED

insulatinglaminatedtempered

Overview

• Şişecam Deco patterned glass is a roller-pressed decorative glass designed to provide controlled light transmission and varying levels of visual privacy for architectural and interior applications.
• It brings brightness and a sense of spaciousness to narrow or poorly lit areas while offering options for view control depending on the chosen pattern.
• Suitable for both interior and exterior use when processed according to project requirements.

Production Method
Patterned glass is produced by passing molten glass between two metal rollers, one of which carries the pattern. The roller process defines thickness and surface texture; pattern depth and texture determine light and image transmittance. The glass is compatible with common downstream processing: edge finishing, lamination, tempering, bending and insulating glass unit assembly. During lamination the patterned surface should face outwards. Where safety is required the glass must be used in tempered or laminated form.

Colors and Patterns
A range of patterns is available from classic to modern motifs. Each pattern delivers different view control values and unique light/image transmittance characteristics to suit design or functional needs.

Areas of Use
Şişecam Deco patterned glass is suitable for decorative surfaces in residential, commercial and public buildings. It is commonly specified where a balance of natural light and privacy is required.

Main Areas of Use

• Windows
• Furniture and cabinet doors
• Interior doors
• Shower cabins
• Coffee tables
• Partitions
• Shelves

Quality
Produced in accordance with TS EN 572-5 (Glass in building - Basic soda lime silicate glass products - Part 5: Patterned glass). Quality control ensures consistent pattern replication and dimensional tolerances suitable for building applications.

View Control and Optical Characteristics
Each pattern has defined view control and optical transmission properties. Pattern depth and surface texture affect light diffusion and image distortion; selection should be based on required privacy and light levels for the project.

Thickness and Size
Thickness and dimensional options depend on production runs and project specifications; refer to Şişecam for available sizes and thicknesses.

Notes

• When produced from low-iron raw materials, patterned glass can be used in photovoltaic module applications (solar panels and collectors).
• Patterned glass is described as environmentally friendly regarding raw materials and the roller production technique.

Technical specifications

• Brand: Şişecam
• Commercial name: Şişecam Deco Patterned (Şişecam Patterned Glass)
• Standards: Produced in accordance with TS EN 572-5
• Production method: Roller process (molten glass passed between two rollers, one patterned)
• Processes supported: edge processing, lamination, tempering, bending, insulating glass units (double glazing)
• Lamination orientation: patterned surface should face outwards
• Safety options: can be laminated for safety; can be tempered where safety is required
• Use in photovoltaics: possible when produced with low-iron raw materials
• Light Transmittance: -
• U Value: -
• Solar Factor: -
• Tempered: Yes
• Shading Coefficient: -
