Built-in downlight 190193
LEDcircularIP20

Built-in downlight - 190193 - s.LUCE - LED / circular / IP20
Built-in downlight - 190193 - s.LUCE - LED / circular / IP20
Built-in downlight - 190193 - s.LUCE - LED / circular / IP20 - image - 2
Built-in downlight - 190193 - s.LUCE - LED / circular / IP20 - image - 3
Built-in downlight - 190193 - s.LUCE - LED / circular / IP20 - image - 4
Built-in downlight - 190193 - s.LUCE - LED / circular / IP20 - image - 5
Built-in downlight - 190193 - s.LUCE - LED / circular / IP20 - image - 6
Built-in downlight - 190193 - s.LUCE - LED / circular / IP20 - image - 7
Built-in downlight - 190193 - s.LUCE - LED / circular / IP20 - image - 8
Add to favorites
Compare this product
Go to the s.LUCE website for more information

Characteristics

Type
built-in
Light source
LED
Shape
circular
Protection class
IP20
Interior/exterior use
indoor
Applications
for office, retail, kitchen, living room
Material
brushed brass, brushed aluminum
Color
white, black, silver-colored, gold-colored
Dimmable
dimmable
Style
contemporary
Number of lights
single, multiple
Other characteristics
orientable, DALI, swivel
Height

40 mm
(2 in)

Length

138 mm
(5 in)

Width

125 mm, 138 mm
(5 in, 5 in)

Luminous flux

840 lm

Color temperature

2,700 K, 4,000 K

Color rendering index (CRI)

Max.: 100 unit

Min.: 93 unit

Description

Overview
The s.luce Santa Deep recessed LED spot combines contemporary design with practical functionality. Designed for residential and commercial settings, it provides directed lighting, high color fidelity and a modular design that allows replacement of the LED plate.

Design and options
Available in several finishes (white, black, brushed gold, brushed aluminum). The adjustable head allows beam direction to be adapted to requirements. Modular design: head and base can be combined in different finishes.

Light quality
Color rendering index CRI >92 ensuring excellent color reproduction. Two color temperatures offered: extra warm white (2700K) and neutral white (4000K). Specified luminous flux: 840 lumens (product value).

Performance and durability
Estimated lifetime up to 25,000 hours. Integrated and replaceable LED plate (replacement recommended by qualified personnel to preserve safety and warranty). The product is dimmable (phase-cut) and offers optional DALI compatibility depending on installation.

Usage features
The Santa Deep head tilts up to 70° and can rotate 360° depending on mounting, allowing precise aiming of the light point. Suitable for kitchens, living rooms, offices, retail and other spaces requiring targeted, adjustable illumination.

Installation information
Recess depth required: 4 cm. Cut-out diameter: 12.5 cm. Overall outer diameter: 13.8 cm. The luminaire requires sufficient ceiling clearance for recessing and, depending on the version, integration of a DALI driver.

Technical characteristics / specifications
  • Model: Santa Deep
  • Brand: s.luce
  • Luminous flux: 840 lm
  • Color temperatures: 2700K (extra warm white) or 4000K (neutral white)
  • Color rendering index: CRI >92
  • Lifetime: up to 25,000 hours
  • Source: integrated, replaceable LED plate
  • Dimmability: phase-cut (compatible with appropriate dimmers)
  • Option: DALI compatibility (depending on installation)
  • Adjustment: head tiltable up to 70° (rotation possible)
  • Recess depth: 4 cm
  • Cut-out diameter: 12.5 cm
  • Outer diameter: 13.8 cm
  • Colors / finishes: white, black, gold, brushed aluminum
  • Applications: residential, kitchen, living room, office, retail
