Metal frame tensile structure MIRAMAS
roofwith PVC membranefor athletic fields

metal frame tensile structure
metal frame tensile structure
metal frame tensile structure
metal frame tensile structure
metal frame tensile structure
Add to favorites
Compare this product


Characteristics

Type
metal frame
Applications
roof
Membrane material
with PVC membrane
Market
for athletic fields, for stadiums
Other characteristics
translucent

Description

Largest athletics hall in Southern Europe. A multifunctional hall: athletics and entertainment hall, gymnasium, central reception area. Capacity: 5500 seats in athletics configuration; 7500 seats for the other configurations. Materials used : TIMBER : 1,200 m3 of glue-laminated timber and 25,000 assembly pins were required to build the framework. Lattice with an 82m span. STEEL : 200 tons of steel structure and solidify this exceptional structure of outstanding proportions. TEXTILE MEMBRANE : 30,000 m² of Ferrari fabric covers the structure. Fabric translucency: 8 à 12 %. Tensile strength: 8 tonnes / linear metre. CONCRETE : Reinforced concrete foundations and stands. COMPLETION DATE 2018 SURFACE AREA 15,000 m² (FLOOR SPACE) Athletics hall: 130 x 82 metres, with a 200 metre track. Gymnasium: 67 x 25 metres.
