Demountable partition EVERWALL™

mobilemodularfabric

Overview
Everwall™ is a prefabricated wall system that balances acoustic performance, aesthetic options and cost. It enables fast installation and flexible space configurations — from enclosed booths to meeting rooms and private offices — using a kit of reusable parts.

Key benefits

• Hybrid-unitized design combining advantages of unitized and stick-built systems for fast installation and design freedom.
• High acoustic performance achieved with acoustic seals on frames, skins and doors.
• Ceiling track compatible with common ceiling types; allows glass and solid panels to tilt and lock into place.
• Simple to reconfigure or relocate; reusable kit reduces onsite material use and construction waste.

Performance Features

• Hybrid-Unitized System: enables both speed of installation and flexibility in layout and finishes.
• Acoustic Performance: seals at frames, skins and doors to deliver enhanced acoustic privacy.
• Ceiling Track: connects to typical ceiling conditions and secures panels by tilting and locking into position.

Sustainability
Everwall™ is designed around reduce, reuse and recycle principles. Prefabrication in a controlled environment reduces onsite work and waste.

• Reduced onsite material handling
• Less cutting and dust generation
• Lower construction waste through reuse

Design Features

• Glass Front Options: a broad range of glass front solutions covering performance, aesthetics and budget needs.
• Expanded Materials: extended palette including luxe paints, laminates, fabrics and markerboards.
• Hardware Options: selection of handles, ladder pulls and hinges in satin stainless, polished chrome and black finishes.

Additional product information
Designed to provide a predictable experience for installers and users; Steelcase offers specification tools, shortened lead times and project support to ensure reliable installation and execution.

Technical specifications

• Unitized Glass Panels
  • Width: 12" to 60"
  • Height: 84" to 120"
  • Glass Thickness: 1/4" (6mm) or 3/8" (10mm) tempered or laminated glass
  • +/- 1/2" vertical allowance at top
  • +/- 3/4" vertical adjustment at bottom
• Butt-Jointed Glass
  • Width: 12" to 144"
  • Height: 84" to 120"
  • Glass Thickness: 3/8" (10mm) or 1/2" (12mm) tempered or laminated glass
  • +/- 1/2" vertical allowance at top
  • +/- 3/4" vertical adjustment at bottom
• Solid Panels
  • Structural Frame Components
    • Width: 8" to 60"
    • Height: 84" to 120"
    • +/- 1/2" vertical allowance at top
    • +/- 3/4" vertical adjustment at bottom
  • Solid Skins
    • Width: 8" to 120"
    • Height: 12" to 120"
    • Orientation: Landscape or Portrait
    • Can span up to four frames
• Power / Data
  • Modular and hardwire power options available
• Clerestory
  • Clerestory Glass Frame Width: 12" to 60"
  • Frame Height: 84" to 120"
  • Glass Height: 16" to ceiling height minus 12"
  • Glass Thickness: 3/8" (10mm) tempered or laminated glass
  • +/- 1/2" vertical allowance at top
  • +/- 3/4" vertical adjustment at bottom
• Swing Doors
  • Width: 28-48" in 1/16th inch increments
  • Height: 84-120" in 1/16th inch increments
  • Glass Thickness: 3/8" (10mm), 1/2" (12mm) tempered glass
  • +/- 1/2" vertical allowance at top
  • +/- 3/4" vertical adjustment at bottom
• Slider Doors
  • Width: 40-48" in 1/16" increments
  • Height: 84-120" in 1/16" increments
  • Glass Thickness: 3/8" (10mm), 1/2" (12mm) tempered glass
  • +/- 1/2" vertical allowance at top
  • +/- 3/4" vertical adjustment at bottom
