Suction System
• NMV direct drive
• Twin-900dia fans which are operated in tandem
• Operational fan speed variable between
2400 RPM – 4000 RPM to suit operation
• HydraDrive
Rear Hydraulic Articulated Power-Arm
• Patent pending hose rotation system
• 250mm hose diameter
• 4.1m range, 180° pivot
Electrical System
• CAN-bus iSS (Intelligent Suction System)
• STODD (Stock Total Onboard Diagnostic Display)
• 24 volt
• Hour Meter
• All external loom connections are full automotive
IP67 rated
Hopper, Lid & Fan Enclosure
• Hopper & lid fabricated from heavy-duty stainlesssteel plate
• Fan enclosures are fabricated from mild steel plate
• Fan enclosures are lined with frequency matched
soundproofing material
• Painted in One Solid Colour
• Dual (2x) Stabiliser Legs
Compressed Air
• Screw compressor
• Jet Spade XT™ trenching tool
• 9m3/min, 7bar
• Oiled, 7m retractable rear-mounted pneumatic hose
reel (for use with air tools which require lubrication)
• Clean, 7m retractable rear mounted pneumatic hose
reel (for use with the Jet Spade XT trenching tool)
Anti-static Discharge
• 14m retractable rear-mounted earthing
hose reel
