Ceiling air diffuser RASTER

squaremetalhome

Raster grille for extract air/transfer air designed for square suspended ceiling systems Used in square suspended ceiling systems Can be placed directly in the T15/T24 Lay in suspended ceiling system Can be used in combination with Swegon’s ADAPTER for suspended ceiling systems Standard finish white RAL 9003/NCS S 0500-N Square raster grille for extract-/transfer air. Designed for installation in suspended ceiling systems. Can be installed in Swegon’s ADAPTER for suspended ceiling systems. Non-painted finish and other colours available on request. The grille is made of aluminium and is painted. RAL 9003, signal white, gloss 40 Alternative standard colours: RAL 9006, white aluminium, gloss 80 RAL 9007, grey aluminium, gloss 80 RAL 9010, pure white, gloss 40 RAL 9005, jet black, gloss 35 RAL 7037, dusty grey, gloss 30 A flow measuring damper installed in the duct system is recommended for commissioning and air flow measurements. Clean the grille if needed with lukewarm water and dishwashing detergent added. Alternatively, use a vacuum cleaner with a brush nozzle when cleaning. The duct system is accessed easily by lifting the grille from the suspended ceiling system/ADAPTER.
