Indoor sports flooring LUMAFLEX EVOLUTION E OMNISPORTS SPEED

birchvinylfor school

Overview
Sports flooring system for multi-sports halls where installation speed and project constraints are priorities. The Lumaflex Evolution sub-construction combined with Omnisports Speed meets EN 14904 C3 classification. The system provides up to 54% shock absorption and is suitable for school gyms and community halls. The simplified panel system reduces installation time and labour while maintaining the required technical performance.

Key Features

• Made in France
• High performance (C3-compliant, EN 14904)
• Fast-installation solution for multi-sports
• Resistance for intermediate multi-use
• Up to 54% shock absorption for improved comfort and safety
• Guaranteed 15 years

Available colours (examples shown)

• Uni Tonic Blue
• Uni Sky Blue
• Uni Teal
• Uni Tonic Green
• Uni Tonic Yellow
• Uni Tonic Orange
• Uni Tonic Red
• Wood Nordic Oak
• Uni Silver Grey
• Concrete Cool Grey
• Uni Grey
• Uni Black

Environmental / Technical - Product formats & facts

• Omnisports Speed available as a 3.45 mm vinyl wearing layer
• Omnisports Compact available in 2 m wide rolls (when applicable)
• Lumaflex Evolution panels: 2400 x 1200 x 18 mm panels
• Panels manufactured exclusively from birch with single tongue & groove interlocking system
• Tarfoam 60: 15 mm polyurethane foam for comfort layer
• Tarfilm: polyethylene vapour protection film

Construction (system composition)
1: SUPERIOR PERFORMANCE AND LONG-TERM SAVINGS
Omnisports Speed (3.45 mm) is supplied with the factory-applied Top Clean XP™ surface treatment to increase durability and simplify maintenance.

2: RESISTANCE & STABILITY
Lumaflex Evolution panels (18 mm) made from birch with a single tongue & groove interlock provide resistance to point and rolling loads and ensure dimensional stability.

3: COMFORT & PERFORMANCE
Tarfoam 60 (15 mm polyurethane foam) provides the comfort layer and contributes to shock absorption.

4: EFFECTIVE PROTECTION AGAINST HUMIDITY
Tarfilm polyethylene film protects the floor system from ground vapour.

Installed references (examples)

• Léo Lagrange gymnasium — Val de Reuil, France — installed 2022 (approx. 1 400 sqm)
• Idrottshuset Jönköping — Jönköping, Sweden — installed 2019 (approx. 1 000 sqm)
• Jean Granelle Gymnasium — Villeneuve Loubet, France — installed 2020 (approx. 1 000 sqm)

Documentation & certificates available
Product brochure, declaration of performance (DoP) and technical datasheet are published for this product. Some certificates or specification documents may require access rights.

Characteristics / technical specifications

• Commercial name: Lumaflex Evolution E Omnisports Speed
• Brand: Tarkett Sports
• Classification: C3 (EN 14904)
• Shock absorption: up to 54%
• Wearing layer: Omnisports Speed 3.45 mm with Top Clean XP™ treatment
• Panel thickness: 18 mm (Lumaflex Evolution panels)
• Panel dimensions: 2400 x 1200 x 18 mm
• Underlayer: Tarfoam 60 (15 mm polyurethane foam)
• Vapour barrier: Tarfilm polyethylene film
• Panel material: Birch (single tongue & groove interlock)
• Format options: rolls for vinyl layers; panels for Lumaflex Evolution
• Maintenance: simplified maintenance due to Top Clean XP™ surface treatment
• Warranty: guaranteed 15 years (manufacturer statement)
