Pellet heating stove ONNY AP 800 5S

5 kW...10 kW10 kW...20 kWmulti-fuel

Description
A glass side to see, feel and experience every spark. Distinctive design that integrates into contemporary spaces. A practical solution combining aesthetics, reliability and user comfort to deliver controlled, efficient air heating for daily use.

Product overview
Pellet-fired stove designed for air heating.

• Triple independent ventilation: a central adjustable centrifugal fan with ducted upper vent or horizontal front outlet, plus two upper centrifugal fans for ducting to a counter-hood or other rooms.
• Electromechanical system for automatic brazier cleaning.
• Quick-access ash collection compartments.
• Upper flue outlet.

Additional information
Dimensions and weight: L 1182 mm, W 500 mm, H 1468 mm, 150 kg

Standard equipment

• DCS: double combustion of the fumes
• Comflux: controlled flow of combustion air
• Soft mode: silent mode
• Brushless pellet loading motor
• Automatic cleaning of the brazier
• Ducting with 2 independent centrifugal fans
• Front ventilation with centrifugal fan
• Integrated inspection T
• Upper flue outlet Ø 100 mm
• Finishing edge

Technical data
Thermochemical Power — max: 13.5 kW; min: 6.4 kW
Nominal Thermal Power — max: 12.8 kW; min: 6.2 kW
Performance — max: 95 %; min: 97 %
Power to the air — max: 12.8 kW; min: 6.2 kW
Tank capacity: 40 kg
Smoke exhaust outlet: Ø 100 mm
Draft: 12 Pa
Power supply voltage: 230 V, 50 Hz
Maximum electrical consumption during operation: 121 W

Characteristics / technical specifications

• Type: Pellet-fired stove for air heating
• Triple independent ventilation (central adjustable centrifugal fan + 2 upper centrifugal fans)
• Automatic brazier cleaning (electromechanical)
• Ash collection: quick-access compartments
• Upper flue outlet diameter: 100 mm
• Dimensions: L 1182 mm × W 500 mm × H 1468 mm
• Weight: 150 kg
• Thermochemical power: 6.4–13.5 kW
• Nominal thermal power: 6.2–12.8 kW
• Performance: 95% (max) / 97% (min)
• Tank capacity: 40 kg
• Power supply: 230 V, 50 Hz
• Max electrical consumption: 121 W
