Entry door 200 DGU

woodenaluminiumswing

VELFAC 200 - the stylish and sophisticated window with double glazing All units have uniform sightlines, whether fixed, opening or motorised, and recessed installation also delivers a 'floating' sash, adding to the contemporary finish. The minimalistic design is a VELFAC characteristic. The VELFAC 200 System consists of windows, casement doors and sliding casement doors in wood/aluminium. Technical specifications Outward opening elements in wood / aluminium SBD accredited Extensive test programme Uw value: down to 1.36 Glazing options: 24mm double glazing A comprehensive 12 year warranty Features - 2-leaf with French casement. - Available as single leaf. - The sash stops at 90°. - Threshold: 15mm or 52mm. - Concealed hinges. - Available as 24mm double glazing. Fittings Egress doors – Fitted with an internal handle only. - The espagnolette has a built-in ventilation position (5mm). - An adjustable friction brake can hold the casement door open in any ventilation position. - Three-four concealed, corrosion-proof hinges. - The friction brake is made of steel with a grey corrosion proof zinc-aluminium surface treatment. Threshold - 15mm HELO® threshold in a grey hardwearing surface finish or - 52mm threshold with aluminium rail. Alternative fittings - Also available with 180° hinge, but this option is without a friction brake. The door can then be no more than 1000mm wide and there may also be restrictions on glass weight. - In order to open 180°, the casement door should be set back by a maximum of 50mm from the facade. N.B. Requires minimum 10mm sealant between frame and masonry.
