Floor fan ARIANTE TOWERresidentialaluminumABS

floor fan
floor fan
floor fan
floor fan
floor fan
floor fan
floor fan
Add to favorites
Compare this product
indicative price

Characteristics

Installation
floor
Sector
residential
Material
aluminum, ABS
Air flow

Min.: 0 m³/h (0 ft³/h)

Max.: 2,323 m³/h (82,036 ft³/h)

Description

Description • Outer casing, base, tangential (cross-flow) impeller, scroll and remote control shell moulded from thermoplastic resin (ABS). • Supporting structure provided by two extruded aluminium columns, one on either side, connected to the base and rotatable about a vertical axis through 60° approx to channel the flow of air in the preferred direction • 3 speed induction motor with start capacitor, shaft turning in high quality self-aligning and self-lubricating bushings; protected by thermal load limiter • Air flow 1300 m3/h • Mechanism inducing oscillation about vertical axis, driven by synchronous electric motor. • Infrared remote control supplied as standard • Remote control functions duplicated by Soft Touch local controls positioned at the top of the tower and protected by a cover provided with cushioned retaining catch. • Set of luminous indicators located on the top front section of the tower casing, showing the selected operating mode of the appliance • PVC power cord, length 2 m, with 10A moulded plug (versions also available with Schuko 16A plug and UK 13A plug).
