Resin resin injection system WEBAC® 4170T

for foundation improvement

WEBAC® 4170T is a universal low viscosity epoxy injection resin suitable for various crack conditions, also at low temperatures. Range of Application Structural filling of cracks and cavities/voids in concrete according to EN 1504-5 (CE-Declaration of Performance/2+) Foundation repair in wind power plants Repair of oil-contaminated cracks and damp cracks Properties Mixing ratio 3 : 1 Suitable at low temperatures Very low viscosity Suitable for damp and oily crack edges Good adhesion Total solid Application Injection by 1C pump WEBAC® 4170T: epoxy resin for use at low temperatures especially designed for damp, wet or oily cracks WEBAC 4170T is a highly reactive special EP injection resin of low viscosity (EP low temperature). It is used for the closing, sealing and bonding of dry, damp or water-bearing cracks and cavities without hydrostatic pressure at low temperatures (epoxy low temperature). Thanks to its low viscosity and good compatibility with moisture WEBAC® 4170T has ideal spreading properties. It also has a good wetting effect and ensures firm anchorage on dry, damp or wet mineral crack edges. WEBAC® 4170T (epoxy low temperature) can be used at temperatures over 5 °C The pot life (1 l) of WEBAC® 4170T amounts to about 20 minutes at 20 °C. The material quantity and layer thickness influence the curing process: higher temperatures accelerate, lower temperatures slow down the strength development – especially if applied in thin layers. The ambient temperature and the temperature of the structural element must be over 5 °C for the application of WEBAC® 4170T.
