Contemporary wall light CONVEXindoorpainted steelgalvanised steel
Add to favorites
Compare this product
Characteristics
- Style
- contemporary
- Interior/exterior use
- indoor
- Material
- painted steel, galvanised steel
- Diffuser shape
- curved
- Type of support
- fixed
- Applications
- for public space
- Light source
- LED, halogen
- Number of lights
- 1 bulb
- Protection class
- IP20, IP44
- Color
- black, silver-colored
- Dimmable
- dimmable
- Designer
- not specified
- Other characteristics
- dimmable
- Height
170 mm
(7 in)- Length
270 mm
(11 in)- Power
Min.: 9 W
Max.: 35 W
- Luminous flux
505 lm
- Color temperature
3,000 K
- Color rendering index (CRI)
Min.: 80 unit
Max.: 100 unit
Description
Overview
Surface-mounted wall luminaire available in LED 9W (505 lm) or GU10 versions. Designed for architectural interiors where compact, indirect wall lighting is required.
Finish and diffuser
Painted or galvanized steel housing. Diffuser in matt tempered glass for even light distribution.
LED information
System power: 9W. Luminaire luminous flux: 505 lm. Correlated colour temperature (CCT): 3000K. SDCM: 3. CRI >80.
Installation
Surface-mounted on wall; suitable for standard wall fixings. Provide access to terminal block for wiring.
Connection
Terminal block 3x4 mm2. For HFF variants use 5x4 mm2 connection.
Variants and article codes
Technical specifications
Designer & notes
Designed by Jens Fager, 2014. HFF = dimmable driver (DALI, DSI or SwitchDim). Other finishes and special configurations available on request.
Surface-mounted wall luminaire available in LED 9W (505 lm) or GU10 versions. Designed for architectural interiors where compact, indirect wall lighting is required.
Finish and diffuser
Painted or galvanized steel housing. Diffuser in matt tempered glass for even light distribution.
LED information
System power: 9W. Luminaire luminous flux: 505 lm. Correlated colour temperature (CCT): 3000K. SDCM: 3. CRI >80.
Installation
Surface-mounted on wall; suitable for standard wall fixings. Provide access to terminal block for wiring.
Connection
Terminal block 3x4 mm2. For HFF variants use 5x4 mm2 connection.
Variants and article codes
- LED 505LM/9W | Black | IP44 | 8290-1-06
- LED 505LM/9W | Black | IP20 | 8290-1-06HFF
- LED 505LM/9W | Galvanized | IP44 | 8290-1-83
- LED 505LM/9W | Galvanized | IP20 | 8290-1-83HFF
- GU10/max35W | Black | IP44 | 8292-1-06
- GU10/max35W | Galvanized | IP44 | 8292-1-83
Technical specifications
- System power: 9W (LED) or GU10/max 35W options
- Luminaire luminous flux: 505 lm (9W LED)
- Colour temperature: 3000K
- SDCM: 3
- CRI: >80
- Finish: Painted or galvanized steel
- Diffuser: Matt tempered glass
- Installation: Surface mounted wall installation
- Connection: Terminal block 3x4 mm2 (HFF: 5x4 mm2)
- Classification: IP20 or IP44 depending on version
- Designer: Jens Fager (2014)
- Standard colours: Black and galvanized; other colours on request
Designer & notes
Designed by Jens Fager, 2014. HFF = dimmable driver (DALI, DSI or SwitchDim). Other finishes and special configurations available on request.
