LED strip light SLOTLIGHT INFINITY SLIM

aluminum

Overview
The SLOTLIGHT infinity slim is an LED continuous light line developed for architectural integration and functional lighting in commercial interiors. Configure continuous runs, corners and installation types with the mySLOT infinity SLIM Configurator. Suitable for reception areas, corridors, offices and open-plan spaces.

Key data

• Designs: Linear and corner
• Lengths: From 1 m, in 250 mm increments
• Mounting: Recessed, surface-mounted, pendant
• Optics: Opal cover, Office cover, Wallwasher, Minicell reflector
• Colour temperatures: 2700 K, 3000 K, 4000 K
• Lumen packages: 1600 lm/m (opal cover, 4000 K); 1200 lm/m (Office cover, 4000 K); up to 3500 lm/m with Minicell

Features

• Approximately one third narrower than the standard family
• Only 45 mm thick
• Enables extensive design flexibility, including integration in jointed ceilings as a functional lighting element

Product characteristics

• Extremely narrow LED light line with consistent aesthetic
• Three-dimensional, linear and dynamic appearance
• Channel, end caps and cover sheet in powder-coated aluminium
• Individual luminaires supplied as factory-assembled complete units
• On-site assembly of continuous runs by combining individual luminaires
• Zumtobel cord suspension kits available for single luminaires and continuous lines

Corners and continuous illumination

• Designed to guide light smoothly around corners
• Illuminated L-connectors and 90° angle modules function as connectors and part of the luminaire
• Continuous illumination with uniform visual appearance even at corners

Minicell (high-performance optics)

• Minicell reflector meets workplace lighting requirements per EN 12464:2011
• Very high lumen outputs possible — up to 3500 lm/m (UGR < 19 achievable)
• Combined with wide distribution, ensures homogeneous illumination for offices, schools and meeting rooms
• Slim Minicell version: increased lumen output (up to 2500 lm/m in Slim Minicell)
• Light distribution angle: 70° for flexible room layouts
• Modular optics to create tailored light scenes

Optic supply and installation

• Optic supplied as continuous diffuser roll (lengths: 8, 10, 15 and 20 m; standard 20 m)
• Can be cut to length on site for single-person installation
• Blue protective film protects the luminaire during construction

Optics descriptions

• Opal cover: Diffuse lens producing a homogeneous light line suitable for receptions, corridors, lounges and breakout zones
• Office cover: Reduces glare to UGR < 19; suitable for workplace lighting to EN 12464:2011 (approx. 1400 lm/m in standard variants)
• Decorative wall washer: Asymmetric distribution for even illumination of vertical surfaces or artwork; reflector is internal and not visible from outside

Technical specifications

• Model name: SLOTLIGHT infinity slim
• Design variants: Linear and corner
• Minimum length: 1 m; increments: 250 mm
• Maximum continuous run: Up to 20 m without interruption or dark spots
• Mounting options: Recessed, surface-mounted, pendant
• Optics options: Opal cover, Office cover, Wallwasher, Minicell reflector
• Colour temperatures: 2700 K, 3000 K, 4000 K
• Lumen packages: Up to 1600 lm/m (opal cover, 4000 K); 1200 lm/m (Office cover, 4000 K); up to 3500 lm/m with Minicell (2500 lm/m in Slim Minicell)
• Glare control: UGR < 19 achievable (Office cover / Minicell configurations)
• Light distribution angle (Minicell): 70°
• Thickness: 45 mm
• Materials: Channel, end caps and cover sheet in powder-coated aluminium
• Corner solutions: Illuminated L-connectors and 90° angle modules for continuous illumination around corners
