Ombrelone octogonal LYBRA

com sistema de inclinaçãoorientávelcentral

Product overview
Turn the handle, the canopy tilts: Lybra is the octagonal garden parasol with EquiTilt® technology integrated into the handle. The sun moves, the shade has to follow. Whether it’s a garden party, a dinner with friends by the pool or a Sunday family lunch: the shade follows the sun — adjust the tilt with a single motion.

Main features

• EquiTilt® on the toothed handle: tilts the canopy with no external lever
• Acrishade 260 gsm fabric: UPF 50+, solution-dyed acrylic with certified colour retention (1,500 hours)
• Eight aluminium ribs (14×20 mm): commercial-grade ribs that keep the canopy taut
• Crank opening: easy opening and closing
• Manual 360° rotation: rotate the pole in the base to direct shade in any direction
• Integrated top air vent: aerodynamic opening at the canopy centre that releases gusts and reduces pressure on the fabric
• Available sizes: Ø 2.7 m, Ø 3.0 m, Ø 3.3 m

The mechanism
Lybra combines two separate, precise actions: a crank for opening/closing the canopy and a toothed knurled handle positioned above the crank socket for gradual EquiTilt® tilting. Rotate the knurled handle to tilt the canopy progressively; the tilt stops at any intermediate position you choose. To change the orientation of the shaded area, rotate the pole manually in the base (360°).

Design & materials

• Canopy: exclusive Maanta Acrishade, 260 gsm, solution-dyed acrylic, water-repellent, UPF 50+
• Frame: aluminium pole Ø 38 mm; eight aluminium ribs 14×20 mm (1 mm thickness)
• Finishes: canopy colours (Graphite, Vellum, Glacier, White, Terracotta, Wheat); frame finishes (Anthracite, Matt Anodizing, Matt White) with curated combinations
• Accessories: compatible bases sold separately; optional protective cover; optional magnetic LED and clip-on LED lamps

Key benefits

• Progressive, precise tilt control without external levers
• Robust aluminium ribs for long-lasting tension and shape
• High-performance outdoor fabric with UV protection and colour fastness
• Integrated air vent improves stability in gusty conditions

Caractéristiques / spécifications techniques

• Denomination commerciale: Lybra
• Available sizes: Ø 2.7 m · Ø 3.0 m · Ø 3.3 m
• Opening and tilt: crank opening · EquiTilt® on the handle (stepless, infinite positions) · manual 360° pole rotation
• Fabric: Acrishade 260 gsm, solution-dyed acrylic, UPF 50+, water-repellent, light fastness certified (1,500 h, grade 4)
• Frame: aluminium pole Ø 38 mm · 8 ribs 14×20 mm (1 mm thickness)
• Integrated top air vent: yes (aerodynamic opening, no external flap)
• Wind resistance: up to 30 km/h (Beaufort 5)
• Headroom beneath canopy: 204 cm (Ø 2.7) · 198 cm (Ø 3.0) · 200 cm (Ø 3.3)
• Total height when open: approx. 250 cm
• Net weight (parasol only): 6.8 kg (Ø 2.7) · 7.7 kg (Ø 3.0) · 8.7 kg (Ø 3.3)
• Box dimensions: 178 × 17 × 17 cm (all sizes)
• Shipping volume: 0.051 m³ (all sizes)
• Packaging: 1 piece per box (parasol only) — anchoring base not included
• Warranty: 2 years on frame · 2 years on Acrishade fabric
• Reference (selected combination): 6302010
• Price (tax excl.): 269.672131 (EUR)
