Wall-mounted exhaust fan VAM

commercialmetalacoustic

Thanks to its slim styling and silent running, the VAM fan is ideal for installation in living spaces. With its powerful AC motor and its optimised design, the VAM can be connected to up to six exhaust units in the same dwelling. Its airflow characteristics (constant-pressure curve) are well suited to operation with demand controlled exhaust units. Silent: only 29 dB (A) @ 100m3/h. Low energy consumption: only 23 W @ 100m3/h. Constant pressure: fitted to demand controlled exhaust units. Easy to install: easy to handle and can be directly installed in living space (in a wall cupboard, corridor, etc.). Choice of 3 settings at the time of installation: 80, 100 and 120 Pa. Outlet 125 mm in diameter Inlets 100 or 125 mm Intelligent motor The VAM is driven by a single-phase asynchronous motor the speed of which is held constant by a tachometer and an electronic board, whatever the airflow required by the exhaust units @ 100m3/h. The power is adjusted and optimised to limit noise and energy consumption. 3 pressures available The VAM provides a choice of three pressure levels at the time of installation: 80, 100, or 120 Pa. This feature can be used to satisfy specific regulations or to compensate for complex ductwork. Installation close to the occupant Because the VAM is silent (acoustic foam) and compact, it is easy to install directly in the living space of the dwelling, in a wall cupboard, a loft space, etc. Maintenance is facilitated by its location within the dwelling.
