- Perimetral captation
The original structure of your hood conceals the grease filters without affecting the efficiency.
- Electronic soft touch controls
The light and air flow regulation is done by a simple one-finger touch on the sensitiv button made of glass. The comfort is guaranteed while the purety of shapes is preserved.
- LED Lighting
To ensure low power consumption and a perfect lighting this model is equipped with LED lighting.
MAIN SPECIFICATIONS
Type of hoods:
Wall decorative hood
Output air extraction (m3/h):
620
Width (cm):
90
CONTROL PANEL
Type of control:
Electronic
Boost position:
None
LIGHTING
Number of lights:
2
Light position:
Under;Right;Left
Type of bulb:
Led
Luminance totale en Lux:
233
Lighting power (W):
3
PERFORMANCE
Number of speed positions:
3
Acoustic power level (recycling) (dBA):
56
Max recycling air extraction (m3/h):
450
Minimum evacuation sound level (dBA):
61
Max evacuation sound level (dBA):
70
FILTERING
Number of filters:
1
No-return airflow clap:
Yes
Accessories:
Characoal filter
DIMENSIONS
Height of product without chimmey (mm):
530
Dimensions of product HxWxD (mm) :
530X900X430
Height of chimmey min/max (mm):
No
Dimensions of the packed product HxWxD (mm):
510X960X640
Gross weight (kg):
20,72
Net weight (kg):
16
CONNECTIONS
Voltage (V):
220-240
Frequency (Hz):
50
Current (A):
10
Connection rating (W):
230
