長方形パラソル CYGNUS DUO

カンチレバー布製アクリル製

Product description
Cygnus Duo is the double-arm cantilever parasol that provides large continuous shade from a single pole (18 m² / 194 sq ft). Designed for terraces, hotel lounges and professional outdoor spaces, it offers a tidy, single-base solution where two separate parasols would be intrusive.

• Independent gas piston: one mechanism per arm — open only the arm you need.
• 360° pole rotation: single lever rotates the central pole so both canopies follow the sun.
• Acrishade 260 g/m² fabric: solution-dyed acrylic, UPF 50+, integrated airvent per canopy.
• Pole 75×124 mm: reinforced cross-section to support the double cantilever load.

Overview
Two cantilever arms are mounted on a single reinforced upright, each arm with its own gas piston for independent opening and closing. The pole can be unlocked and rotated 360° with a lever at the base so both canopies move together. Each canopy features an airvent to reduce wind pressure and perimeter velcro closures to secure the fabric when closed.

Protective cover (optional accessory)
The shaped protective cover (sold separately) is made from weather-resistant polyester with reinforced zip and is specifically sized for the Duo geometry. It is designed to be fitted from top to bottom using an included installation rod and keeps the canopies and frame protected when not in use.

Compatible accessories

• Protective cover for Cygnus Duo (shaped cover for 3×6 configuration)
• Concrete anchor plate (for fixed anchoring)
• Wooden floor anchoring plate (for decking)
• In-ground anchor plate
• Fillable 4-in-1 parasol bases (for weighted, non-fixed installations)

Caractéristiques / spécifications techniques

• Available size: 3 × 6 m (rectangular — two adjacent canopy panels, total coverage 18 m²)
• Opening: push-open one-stop, gas piston assisted, independent piston per arm
• Fabric: Maanta Acrishade 260 g/m², solution-dyed acrylic, UPF 50+, water-repellent; airvent per canopy; perimeter velcro fastening
• Frame: commercial-grade aluminium
• Pole (central upright): 75 × 124 mm (reinforced section)
• Ribs: 16 ribs total (8 per canopy) — aluminium slats (16×28 mm)
• Movement: 360° rotation of the central pole via a single lever at the base (both canopies rotate together)
• Heights: total open height 260 cm; usable headroom under canopy ≈ 210 cm
• Net weight: 50.2 kg
• Wind resistance: up to approx. 25 km/h (recommend fixed anchoring or minimum ballast as specified)
• Warranty: 7 years on frame · 3 years on fabrics
• Packaging (example): gross weight ≈ 60 kg; package dimensions 269 × 78 × 22 cm; 1 piece per package; volume ≈ 0.46 m³
• Package contents: complete Duo parasol — pole, two arms, two pre-mounted canopies, mounting accessories
• Essential but not included: base (fixed anchor plate or weighted base) and shaped protective cover (sold separately)
