Access control speed gate TTSCPR3

glassstainless steelsecurity

Presentation
TTSCPR3 is a compact glass speed lane designed for access control in corporate buildings and sports facilities. It pairs broad glazed panels with a slim stainless-steel frame to deliver a modern, airy appearance and a small footprint.

Design and construction
The structure consists of a slim stainless-steel frame supporting large glazed surfaces to create a sense of space. Encasements are exceptionally narrow and short to minimise floor occupation while enhancing the system's aesthetic integration.

Detection and crossing management
User passage is detected by photoelectric sensors connected to a control board. The board runs advanced algorithms to:

• open the glass leaves only for the time required to pass,
• automatically close the leaves after passage,
• discriminate the simultaneous arrival of two people facing each other.

Operational features

• Bidirectional operation: each lane can be used as both entry and exit,
• 180° swing glass doors opening in the direction of travel for ergonomic access,
• Individual configuration of each lane (entry-only, exit-only or bidirectional) to manage flows when multiple lanes are installed side by side.

Accessible (PMR) version
An accessible version with a 90 cm clear opening is available to meet accessibility requirements and provide comfortable access for wheelchair users. Standard and accessible lanes can be combined within the same lobby while maintaining a homogeneous appearance.

Recommended applications
Designed for corporate headquarters, administrative buildings and sports centres, the TTSCPR3 integrates with badge or biometric systems to provide an aesthetic and secure access control solution.

Characteristics / technical specifications

• Model: TTSCPR3
• Structure: slim stainless-steel frame with large glazed surfaces
• Encasements: exceptionally narrow width, reduced length for minimal footprint
• Detection: photoelectric sensors
• Control: electronic board with timed opening/closing algorithms
• Door type: 180° swing glass leaves
• Passage mode: bidirectional (configurable)
• Accessible version: 90 cm clear opening
• Typical applications: employee access in corporate environments, members access in sports facilities
