PV roof tile NORDIC
solarglassmetal

PV roof tile - NORDIC - AHLUX ITALIA SRL - solar / glass / metal
PV roof tile - NORDIC - AHLUX ITALIA SRL - solar / glass / metal
PV roof tile - NORDIC - AHLUX ITALIA SRL - solar / glass / metal - image - 2
PV roof tile - NORDIC - AHLUX ITALIA SRL - solar / glass / metal - image - 3
PV roof tile - NORDIC - AHLUX ITALIA SRL - solar / glass / metal - image - 4
PV roof tile - NORDIC - AHLUX ITALIA SRL - solar / glass / metal - image - 5
Add to favorites
Compare this product
Go to the AHLUX ITALIA SRL website for more information

Characteristics

Type
solar, PV
Material
metal, glass
Size
large, small
Color
black
Length

18 cm, 49 cm
(7 in, 19 in)

Width

16 cm, 47 cm
(6 in, 19 in)

Description

General Description
  • Curved metal inert roof tile and photovoltaic tile with tempered solar glass protection on a metal body.

Photovoltaic Tile
  • Solar Cell: Monocrystalline Half-Cut 182 mm cells
  • Photovoltaic Module: Glass + EVA + Monocrystalline Solar Cell + EVA + BLACK PET
  • Support/Body: Pre-galvanized metal
  • Body Coating: Powder coated
  • Glass: Tempered glass with 3.2mm thickness, high light transmission, anti-reflective
  • Junction Box: IP68, Class II (Double insulation), πuv
  • Connectors: MC4 certified πuv
  • Cable: 2 x 2.5mm² certified πuv
  • Operating Temperature: -20° C to +80° C

Electrical Characteristics of Photovoltaic Tile
  • Peak Power at STC (Pmax/W): 41Wp
  • Maximum Power Voltage (Vmp/V): 6 V
  • Maximum Power Current (Imp/A): 6.83 A
  • Efficiency: ≥24%

Mechanical Characteristics of Photovoltaic Tile
  • Dimensions: 49x47x60cm
  • Weight: 5.5Kg

Photovoltaic Coppo
  • Support/Body: Pre-galvanized metal
  • Body Coating: Powder coated
  • Operating Temperature: -20° C to +80° C

Electrical Characteristics of Photovoltaic Coppo
  • Peak Power at STC (Pmax/W): 20Wp
  • Maximum Power Voltage (Vmp/V): 6 V
  • Maximum Power Current (Imp/A): 3.33 A
  • Efficiency: ≥24%

Mechanical Characteristics of Photovoltaic Coppo
  • Dimensions: 16x18x60cm
  • Weight: 1.2Kg

Features / Technical Specifications
  • Curved metal inert roof tile
  • Photovoltaic tile with tempered solar glass protection
  • Pre-galvanized and powder-coated metal body
  • Photovoltaic module with monocrystalline Half-Cut 182 mm cells
  • 3.2mm tempered glass, high light transmission, anti-reflective
  • IP68 junction box, Class II
  • MC4 certified connectors
  • 2 x 2.5mm² certified cable
  • Operating Temperature: -20° C to +80° C
  • Efficiency: ≥24%
