Mineral fiber suspended ceiling CASCADE®

panelindooracoustic

Product overview
The Cascade® 24 x 24 in (610 x 610 mm) mineral fiber ceiling tile features a square tegular edge and a stepped visual that enhances ceiling depth. Intended for use in PRELUDE 15/16 in suspended ceiling grid systems. For residential installations, the tile can also be fitted using the QUICKHANG Installation Kit.

Packaging & coverage
Sold by carton: 12 tiles per carton. One carton covers 48 sq ft (4.46 m²). Tile nominal dimensions: 24 x 24 x 3/4 in (610 x 610 x 19 mm).

Performance & features

• Edge profile: Square Tegular, compatible with 15/16 in grid
• Material: Mineral fiber
• Sound Absorption (NRC): 0 (as shown)
• Sound Blocking (CAC): 30 (on a 50 scale)
• Fire rating: Class A (flame spread ≤ 25; smoke developed ≤ 50)
• Standard sag / humidity resistance
• Standard mold / mildew resistance

Additional notes
Carton weight: 43 lb (≈ 19.5 kg). Typical installation uses a standard 15/16 in grid; a 9/16 in grid is a common alternative. A quick estimator tool on the product page helps calculate required quantities for a given area.

Technical specifications

• Product name: Cascade®
• Item: 1270
• Denomination (model): Cascade®
• Edge profile & grid size: Square Tegular, compatible with 15/16 in
• Product dimensions: 24 x 24 x 3/4 in (610 x 610 x 19 mm)
• Package quantity: 12 tiles / carton
• Covers: 48 sq ft (4.46 m²) per carton
• Weight: 43 lb (≈ 19.5 kg) per carton
• Material: Mineral fiber
• Sound Absorption (NRC): 0
• Sound Blocking (CAC): 30
• Fire Rating: Class A
• Sag / Humidity Resistance: Standard
• Mold / Mildew Resistance: Standard
