Sand pool filtration system 05135CE004

for public pool

Product overview
Pre-assembled compact kit for public hot tub installations, integrating filtration, heating and massage functions. Designed for commercial/public use (hotel spas, wellness centres, municipal facilities). Compatible models include Formentera, Coliseum, Olympia, Mirage 40, Odisea 20 Verona, Roma and Tokyo 70.

Codes / variants

• 05135CE004 — Ø500 mm · 0.60 kW · 10,000 l/h · 114 kg
• 05135CE000 — Ø650 mm · 0.82 kW · 11,000 l/h · 94 kg
• 05135CE002 — Ø650 mm · 0.82 kW · 11,000 l/h · 94 kg (variant)
• 16412CE000 — Compact 75 2M · Ø650 mm · 0.82 kW · 11,000 l/h · 116 kg
• 16412CE001 — Compact 75 2M + ozone
• 16412CE004 — Compact 75 2M (with exchanger option)
• 16412CE002 — Kit Compacto 75 2M + Control Ph
• 43639CE001 / 43639CE004 — Tokyo 70 variants (with/without ozone)

Technical specifications

• Pre-assembled system integrating filtration, heating and massage
• Compatible spa models: Formentera, Coliseum, Olympia, Mirage 40, Odisea 20 Verona, Roma, Tokyo 70
• Available pump diameters: Ø500 mm and Ø650 mm
• Typical motor powers and flows: 0.60 kW (10,000 l/h), 0.82 kW (11,000 l/h)
• Weight range by configuration: approx. 94–134 kg
• Optional equipment: ozonator, water-to-water heat exchanger (20 kW), dosing and pH/Redox control

Documentation & images

• Multilingual product datasheets (EN, ES, FR, IT, DE, PT)
• Installation manual and technical sheets (FT10_KIT_75_2M, FT10 Kit Wellmax)
• Image gallery available (product and variant views)

Ordering & spare parts

• Use the product code (CODE) to order specific kit configurations and spare parts
• Contact supplier with the model code and required options (ozone, exchanger, dosing) to confirm compatibility with your hot tub model
