Aluminium suspended ceiling 24 SYNCRO EVO

steeltilepanel

Atena 24 Syncro evo® is the patented technical solution of Atena H+ range, properly conceived for hospitals and cleanrooms thanks to its high air-tight performance. The special springs, hooked on T grid, make an high pressure on neoprene gasket installed along the panels sides, reducing the air flow and guaranteeing the environment cleaning. A second sealing gasket is laid on the perimeter profile. The system hides the structure completely, creating a uniform metal ceiling. This is the perfect solution to renovate ceilings using the existing T grid. The system with Atena Lux Taurus Evo lighting is ISO2 Certified by Fraunhofer Institute. Side by side right edge panels 600×600 |600×1200 mm 300×600 |300×1200 mm Other dimensions on request. Steel 5/10 – 6/10 | Aluminium 8/10 Steel Strong Easy T24 Steel Strong Easy Antisismico T24 Air Cleanliness Class | ISO 14644-1 Metal ceiling and lighting: ISO 2 Fraunhofer institute – Stuggart Chemical resistance VDI2083 P.17; ISO 4628-1; ISO2812-1 Antibacterial post-painted surface Defence H+4 Fraunhofer institute – Stuggart Antimicrobial Assessment certifications ISO 22196 | JIS Z 2801-2010 White – silver pre-painted aluminium White – silver pre-painted steel RAL/NCS Coating Sublimation of any image and effect Plain surface Antibacterial treatment Antiseismic Kit for plenum 1,2 m
