Enigma Matrox Airtight of Atena H+ range is a certified metal ceiling system properly conceived to reduce the air exchange between the plenum and the environment. Equipped with a special neoprene gasket to be installed both along the panel sides and on the wall angles, the system has been certificated for air permeability by Treviso Technology Laboratory in compliance with the ASME MCF-14M:1995 UNI EN ISO 5167-1 1997/A1:2000.
Side by side panels
right or bevelled closed edge
600×600 mm
Other dimensions on request.
Steel 5/10 and 8/10
Stainless steel 5/10 and 6/10
Aluminium 6/10 and 8/10
Matrox
Air tight ceiling system
ASME MCF-14M:1995 UNI EN ISO 5167-1 1997/A1:2000
Treviso Technology Laboratory
Chemical resistance
VDI2083 P.17; ISO 4628-1; ISO2812-1
Antibacterial post-painted surface Defence H+4
Fraunhofer institute – Stuggart
Antimicrobial Assessment certifications
ISO 22196 | JIS Z 2801-2010
White – silver pre-painted aluminium
White – silver pre-painted steel
RAL/NCS Coating
Sublimation of any image and effect
Plain surface
Antibacterial treatment
Antiseismic Kit for plenum 1,2 m
