Clip-in healthcare system
ENIGMA AIRTIGHT is a certified clip-in metal ceiling system, with integrated lighting and air terminal unit, properly conceived for operating theatres and healthcare environments.
This healthcare metal ceiling has been certified for air tightness according to the measurement method of the UNI EN 1026 standard, which includes specific tests with positive and negative pressure.
FEATURES AND DIMENSIONS:
Clip-in side by side panels
Right edge 600×600 mm
Other dimension on request.
MATERIALs:
Steel 5/10 and 6/10 | Aluminium 8/10
Stainless steel on request
STRUCTURES:
TDW-T
Double Triangle with Winger and air tight gaskets.
CERTIFICATES:
Airtight ceiling system
Air permeability test according to UNI EN 1026 with negative and positive pressure
By Istituto Giordano
Chemical resistance
VDI2083 P.17; ISO 4628-1; ISO2812-1
Antibacterial post-painted surface Defence H+4
Fraunhofer institute – Stuggart
Antimicrobial Assessment certifications
ISO 22196 | JIS Z 2801-2010
COLORI | FINITURE | FORATURE:
White – silver pre-painted aluminium
White – silver pre-painted steel
RAL/NCS Coating
Sublimation of any image and effect
Plain surface
Antibacterial treatment
ANTISEISMIC EQUIPMENTS:
Antiseismic Kit for plenum 1,2 m
