SQ Smart Model light element and
bollards combine elegance and purity with
the minimal square shape and generate
softly diffused illumination.
The architecturally adaptable, optically
robust, and energy efficient LED light
system is ideally suited to illuminate any
landscape or architectural context such
as prestigious entrance areas, gardens,
squares and parks.
LED Type - High efficiency LEDs, available in 2700K, 3000K, 4000K, 5000K, 6500K CCT tolerance within a 3-step MacAdams ellipse and LM80 compliant.
Nominal Voltage - 220V-240V AC, 50/60Hz
Color Rendering Index - CRI> 80 standard and CRI>90 on request.
Light Distribution - Rotationally symmetrical light distribution.
Materials - Corrosion resistant double layer polyester powder coated paint finish die cast aluminium housing, aluminium extruded column (EN AW-6060) with stainless steel screws (A4 grade) and silicone gaskets. Power unit is built in. Available in anthracite gray as a standard finish or any desired RAL colour.
Optional Coating - Marine grade.
Diffuser - Opal synthetic diffuser.
LED Specification. - L90B50 > 100000 hours life time.
Energy Effciency Class (EEC) - A++
Operating Temperature - -40°C / +55°C
Power Factor - >0.95
Control Systems - DALI Interface.
Protection Class - IP65
Impact Resistance - IK08
Insulation Class - Class I
Conformity - Complies with European Standards EN 60598 and CE certified.
