Ballet bar Avant-Fix Fitness

Product overview
Designed for high-intensity studio use, the Avant-Fix Fitness is a floor-mounted support for a single wooden barre. Its exclusive structural geometry, featuring a 28 × 14 cm steel base with six fixing points and an integrated diagonal brace, delivers stability under heavy loads and rapid weight shifts. Intended for barre fitness studios, Pilates rooms, functional training areas and gyms, it enables precise, fluid and controlled movements.

Structural stability with advanced geometry
The support uses a 28 × 14 cm steel floor fixing base with six anchors to optimise load distribution. A 50 mm diameter central column and an integrated diagonal reinforcement resist pressure and torsion from any direction, ensuring reliable stability during pushing, pulling and sustained support exercises. Floor fixing is performed with six M10 hexagon anchors (100 mm) to provide secure anchoring for intensive-use environments.

Linear configuration adaptable to any space
With the wooden barre installed at a working height of 105 cm, the system provides an ergonomic position suitable for both technical and functional training. Avant-Fix Fitness supports allow continuous barre runs by joining barres within each 20 cm fixing plate; the required linear length can be configured according to studio layout. The rectangular base permits positioning close to walls or mirrors to optimise space and organisation.

Materials designed for intensive use
The steel structure ensures strength and long-term durability in demanding training environments. The main column and diagonal brace deliver structural resistance while the 20 cm fixing plates secure the barre around its perimeter to distribute pressure evenly and reduce wear. The wooden barre is Melis pine, Ø 40 mm, sourced from sustainably managed forests, offering a natural feel, good grip and controlled flexibility that supports precise movement.

Finishes
Available in white (RAL 9016) and black (RAL 9005), the floor-mounted support integrates into studios that prioritise technical performance and a consistent visual identity.

Technical information (summary)

• Floor fixing base: 28 × 14 cm steel plate with six fixing points
• Central column diameter: 50 mm
• Diagonal reinforcement integrated into column
• Fixing plates for barres: 20 cm perimeter plates for continuous runs
• Barre working height: 105 cm
• Wooden barre: Melis pine, Ø 40 mm (available lengths: 150 cm or 200 cm)
• Anchoring: six M10 × 100 mm hexagon anchors per support (floor anchors)

Assembly instructions (key steps)

• Place the supports in the planned positions and mark the six anchor points per support on the floor.
• Drill six holes approximately 120 mm deep at each support position and insert the M10 hexagon anchors through the base, tightening them firmly.
• Loosen the four small screws on the fixing cradle with the supplied Allen key, insert the wooden barre into the cradle, position it and tighten the screws to secure the barre.
• To join two wooden barres on a single support, insert one barre at each end of the 20 cm fixing plate so they meet centrally.

Included / supplied items (as listed)

• 6 hexagon M10 × 100 mm anchors (per support)
• DIN 7991 M6 × 14 mm A2 screws (x4)
• Allen key 4 mm (x1)

Technical specifications

• Model name: Avant-Fix Fitness
• SKU code (white): 30700341
• SKU code (black): 30700332
• Materials: steel uprights and base (white RAL 9016 or black RAL 9005); Melis pine wooden barre
• Weight: 6.90 kg per support
• Wooden barre: 1 unit | Ø 40 mm | Length options: 150 cm or 200 cm | Melis pine
• Anchors: M10 × 100 mm (x6) per support
• Screws and tools included: DIN 7991 M6 × 14 mm A2 (x4); Allen 4 mm (x1)
• Base dimensions: 28 × 14 cm
• Central column diameter: 50 mm
• Fixing plate length: 20 cm (for joining barres)
