LED track light STELLA

ovalrectangularsquare

Stella are high‑output spotlights, floodlights and lens wallwashers for track systems, engineered for large lighting distances and demanding accent and wall‑washing tasks in high rooms. The range provides two luminaire sizes, a full set of ERCO Spherolit lens distributions and cast aluminium housings for effective thermal management and long service life.

Highlights

• Large lumen packages for very high illuminances, suitable for exhibition spaces, foyers and large public areas.
• Oval flood optics freely rotatable 360° to adapt the light distribution to elongated objects.

Product description

• Available as track‑mounted spotlights, floodlights or lens wallwashers to meet complex lighting tasks flexibly and consistently.
• Two luminaire sizes cover different lumen packages and application heights.
• Spherolit lens optics deliver narrow spot, spot, flood, wide flood, extra wide flood, oval flood and wallwash distributions.
• Cast aluminium housing with powder coating ensures efficient heat dissipation and service life.

Individualisation options

• ERCO individual: extensive options for custom colours and further variants on request (housing: up to 10,000 additional colours available).

Technical specifications

• Light distributions: narrow spot, spot, flood, wide flood, extra wide flood, oval flood (360° rotation) and wallwash (Spherolit lens optics).
• Light sources / output ranges (indicative): spotlights 28.2 W–74.9 W, 2715 lm–8969 lm; floodlights 36.2 W–74.1 W, 3490 lm–8969 lm (depending on configuration).
• LED modules: high‑power LEDs in warm white (2700K, 3000K) and neutral white (3500K, 4000K); collimating lens made of optical polymer.
• Housing and finish: cast aluminium, powder‑coated; standard colours white (RAL9002), black or silver; further colours on request.
• Mechanical adjustment: luminaire head pivotable 0°–90° with screw lock; housing rotatable 360° on the adapter.
• Control / dimming: phase dimmable + On‑board Dim, DALI dimmable or Casambi Bluetooth; phase dimmable + On‑board Dim supports trailing‑edge external dimmers and rotary brightness control on the luminaire.
• Adapters: ERCO 3‑circuit adapter or ERCO DALI adapter for track mounting.
