The presence and motion detectors in the CE series intelligently switch the lighting and impress with their clever design. The concept enables flush ceiling installation and guarantees a correspondingly subtle appearance that, for the most part, only leaves the lens visible. Installation is quick and easy — even express.
SHORTFACTS
Installation typeRecessed mounting
Installation positionCeiling
Protection typeIP40
DimensionsHeight/Depth 32 mm, Ø 82 mm
Power consumption0.3 W
Detection angle360°
Detection range diagonallyØ 24 m
field of detectionup to 453 m²
Light measurementmixed light
Level of brightness5 - 2000 lx
Warranty5 years
TECHNICAL DATA
GENERAL
Special product featuresSimple programming using remote control with "blue mode" technology
ConformityCE , RoHS , WEEE
MOUNTING
Installation typeRecessed mounting
Installation positionCeiling
Installation dimensionInstallation depth: 67 mm, Ø 68 mm
Connection1.5 mm²
HOUSING
DimensionsHeight/Depth 32 mm, Ø 82 mm
Weight233 g
MaterialUV-stabilised polycarbonate
Protection typeIP40
Permissible ambient temperature-25 °C...+50 °C
Relative humidity5 - 93 %, non-condensing
ColourOpal matt
ELECTRICAL VERSION
Protection classII
Nominal voltage230 V / 50 Hz
Power consumption0.3 W
In-rush current800 A / 200 µs
